Diaphragm valves-Weir type
The GMI Branoa diaphragm valve(Weir type) is a valve that controls the fluid flow through the deformation of a flexible component: the membrane. When the valve is open, the stream is deflected.
BRANOA® Threaded diaphragm valves.
Construction : Weir type diaphragm valvesBody material : Cast iron, Stainless steel,...
Diaphragm material : Natural rubber, EPDM, NBR, FKM, Silicone...
Class : PN10
Sizes : Up DN10 to DN80
End connections : Threaded: BSP, NPT
Lining material : Ebonite, Butyl, Halar, Rilsan, PVDF, ETFE, PFA, PTFE...
DINO-BRANOA® Flanged diaphragm valves, weir...
Construction : Weir type diaphragm valvesBody material : Cast iron, Stainless steel,...
Diaphragm material : Natural rubber, EPDM, NBR, FKM, Silicone...
Class : PN10, PN16, PN20, Asa 150
Sizes : Up DN10 to DN250
End connections : Flanges :PN10, PN16, PN20, Asa 150
Lining material : Ebonite, Butyl, Halar, Rilsan, PVDF, ETFE, PFA, PTFE...
-The construction of the diaphragm valves: straight or curved bore.
-The design of the valves: coated or not coated.
-Operating pressure,
-Operating temperature,
-Compatibility of the body and coating materials with the fluid being conveyed.
