Butterfly valves

The GMI butterfly valve is a HIGH-PERFORMANCE valve whose disc rotates about an axis perpendicular to the direction of flow. When it is in the 'open' position, fluid flows around it. There are two types: butterfly valves with metal/metal bearing surfaces, and those with flexible bearing surfaces.

AXISS® Elastomer Butterfly valves

Construction : Body : Wafer, lugged between flanges PN10, PN16, PN20, Asa 150
Body material : Cast iron: GL-GS-GG 25, Carbon steel: A216 WCB-GSC 25, Stainless steel : 304-316…
Disc material : Cast iron: GS-GG 25, Carbon steel: A216 WCB-GSC 25, Stainless steel : 304-316… , Aluminium-bronze, Specials alloys...
Liner material : Hypalon, Nitrile, Viton, Silicone, EPDM, PTFE on soft seat
Class : PN10, PN16, PN20, PN25, Asa 150
Sizes : Up DN32 to DN1400
End connections : With or between flanges : PN10, PN16, PN20, Asa 150
Butterfly valves for industrial application
Dovetail type sleeve
ATEX on request

PRO-AXISS Lined bufferfly valves

lined butterfly valves for corrosion service

Construction : 2 piece split body : Wafer, lugged between flanges PN10, PN16, PN20, Asa 150
Body material : Cast iron : GS-GG 25, Carbon steel: A216 WCB-GSC 25, Stainelee steel: 304-316…
Disc material : Stainless steel: 304-316..., Lined...
Liner material : PTFE, UHMPE
Class : PN10, PN16, PN20,PN25, Asa 150
Sizes : Up DN40 to DN600
End connections : Between flanges: PN10, PN16, PN20,PN25, Asa 150.
Flanges: PN10, PN16, PN20,PN25, Asa 150
High corrosion butterfly valves
ATEX on request

Perfo-Axiss®, High performance butterfly valves

Construction : Body Wafer, lugged between flanges PN10, PN16, PN20, PN25, PN40, PN50, Asa 150, Asa 300, Asa 600
Body material : Carbon steel: A216 WCB-GSC 25, Stainless steel :304-316…, Special alloys...
Disc material : Stainless steel 304-316, special alloys...
Seats material : PTFE soft seat and metal seat (Inconel, Hastelloy...)
Class : PN10, PN16, PN20, PN25, PN40, PN50, Asa 150, Asa 300
Sizes : Up DN40 to DN1200
End connections : Between flanges PN10, PN16, PN20, PN25, PN40, PN50, Asa 150, Asa 300
Double or triple eccentric design high performance butterfly valves.
High temperature, cryogenic and fire safe buttrefly valves.
ATEX on request.

HYDRO-AXISS® Flanged butterfly valves

High size double flanged butterfly valves

Construction : Double flanges
Body material : Cast iron
Disc material : Fonte : GS
Liner material : Epdm, Silicone, FKM...
Class : PN10, PN16, PN20, PN25, Asa 150
Sizes : Up DN150 to DN1400
End connections : Flanges PN10, PN16, PN20, PN25, Asa 150
On request: Gear box, pneumatic actuator, electric actuator.

VENTIL-AXISS® Butterfly valves and dampers

Construction : Cast or welded body
Body material : Fonte / Acier Carbone / Acier inoxydable / Alliages spéciaux...
Disc material : Fonte / Acier / Inox
Seat : Metal /metal
Class : PN2.5, PN6, PN10, PN16
Sizes : Up150 to DN1600
End connections : Between flanges: PN10, PN16, PN20, Asa 150.
Gas and high temperature service.
